76 Publication IASIMP-QS001C-EN-P - October 2009
Chapter 6 Prepare the PanelView Plus Terminal
1769-L31 controller
Connect the 2706-NC13 cable
to the serial port. Connect the
other end of cable to the
Channel 1 port on the 1769-L31
controller.
1756-CP3 Serial Cable to
Channel 0 Port
