Publication IASIMP-QS001C-EN-P - October 2009 211
Create a PanelView Plus Application Chapter 14
6. Verify that the Run application and Replace communications checkboxes are
checked and verify that your PanelView Plus is selected for the destination terminal.
7. Click Download.
8. Click OK.
