Allen-Bradley CompactLogix Series User Manual

99Publication IASIMP-QS001C-EN-P - October 2009 99
Chapter 10
Create a Project Using RSLogix 5000 Programming
Software
In this chapter you create a project in RSLogix 5000 programming software. In the project
you use ladder logic to create a push button that controls a light on a digital output module.
This project is used in subsequent chapters to test communication with other devices.
Before You Begin
• Configure your network:
– for an EtherNet/IP network, see Chapter 7
– for a ControlNet network, see Chapter 8
– for a DeviceNet network, see Chapter 9
What You Need
• A CompactLogix I/O module with digital outputs, this example uses a 1769-OB16.
• This example includes the following modules as well, but they are not required:
1769-IF4, 1769-IQ16, 1769-IF4XOF2, 1769-OF2.

Allen-Bradley CompactLogix Series Specifications

General

Communication Ports	EtherNet/IP
Programming Software	Studio 5000 Logix Designer
Power Supply	24V DC
Series	CompactLogix
Programming Languages	Ladder Diagram (LD), Structured Text (ST), Function Block Diagram (FBD), Sequential Function Chart (SFC)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Mounting	DIN rail
Processor Type	Various (depends on model)
