14 Publication IASIMP-QS001C-EN-P - October 2009
ControlNet Configuration
1 1769-L32CR CompactLogix ControlNet Controller with Redundant Tap
1 1784-PCIC or 1784-PCICS ControlNet Communication Card for a Personal Computer
1 1734-ACNR POINT I/O ControlNet Adapter
1 22-COMM-C ControlNet Adapter for Use With the PowerFlex 40
1 20-COMM-C ControlNet Adapter for Use With the PowerFlex 70
1 2711P-RN15S PanelView Plus 1000 ControlNet Interface Module
6 1786-TPR ControlNet Tap
2 1786-XT ControlNet Terminating Resistor
5 1786-BNCP ControlNet BNC Coaxial Connector
Serial Configuration
1 1769-L31 1769-L31 CompactLogix Controller
1 1756-CP3 RS-232 cable
1 2706-NC13 Point-to-Point RS-232 Cable
DeviceNet Configuration
1 1769-SDN Compact I/O DeviceNet Scanner
1 1734-ADN POINT I/O DeviceNet Adapter
1 22-COMM-D DeviceNet Adapter for use with the PowerFlex 40
1 20-COMM-D DeviceNet Adapter for use with the PowerFlex 70
1 1606-XLDNET8 DeviceNet Power Supply
N/A 1485C-P1E75 KwikLink Flat Cable
2 1485A-T1E4 KwikLink Terminator/Resistor
4 1485P-P1E4-R5 KwikLink Sealed Micro Connector
4 1485K-P1F5-C KwikLink Right-angle Male to Cable
1 1485T-P1E4-B1 KwikLink Power Tap Module
(1)
The 1769-OB16 module is the only Compact I/O module used in this quick start. The other modules are added as examples only and are not required.
(2)
Use Point I/O modules at series C or later to complete examples in this quick start.
(3)
The 1734-OB4E module is the only POINT I/O module used in this quick start. The other modules are added as examples only and are not required.
Quantity Catalog Number Description
