Allen-Bradley CompactLogix Series User Manual

3Publication IASIMP-QS001C-EN-P - October 2009 3
Where to Start
Follow the path that matches your hardware and network configuration.
Chapter 10
Create a Project Using RSLogix 5000
Programming Software
Chapter 1
Prepare the CompactLogix Hardware
Chapter 2
Prepare the Computer
Chapter 3
Prepare the Distributed
POINT I/O Hardware
Chapter 4
Prepare the PowerFlex 70
Drive
Chapter 5
Prepare the PowerFlex 40
Drive
Chapter 6
Prepare the PanelView Plus
Terminal
Chapter 7
Configure the EtherNet/IP
Network
Chapter 8
Configure the ControlNet
Driver
Chapter 9
Configure the DeviceNet
Network
Chapter 11
Add Distributed I/O
Modules to the Project
Chapter 12
Create a PowerFlex 70
Application
Chapter 13
Create a PowerFlex 40
Application
Chapter 14
Create a PanelView Plus
Application
Required
Required
Optional
Depending on your system.
Optional
Depending on
your networks.
Required
Optional
Depending on your system.
page 17
page 27
page 55 page 63page 47 page 71
page 81 page 87 page 91
page 99
page 113 page 143 page 167 page 189

Allen-Bradley CompactLogix Series Specifications

General

Communication Ports	EtherNet/IP
Programming Software	Studio 5000 Logix Designer
Power Supply	24V DC
Series	CompactLogix
Programming Languages	Ladder Diagram (LD), Structured Text (ST), Function Block Diagram (FBD), Sequential Function Chart (SFC)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Mounting	DIN rail
Processor Type	Various (depends on model)
