Publication IASIMP-QS001C-EN-P - October 2009 33
Prepare the Computer Chapter 2
10. Click Next to
install the typical
firmware kits.
11. Click Next to install
typical RSLogix
Architect tools.
12. Click Next to install
the typical set of
EDS files and
RSLinx software.
