Logic Functions Command Reference 145
Truth Table for Four-input AND Evaluation
Input 1 Input 2 Input 3 Input 4 Output 1
0 x x x 0
x 0 x x 0
x x 0 x 0
x x x 0 0
1 1 1 1 1
Truth Table for Five-input AND Evaluation
Input 1 Input 2 Input 3 Input 4 Input 5 Output 1
0 x x x x 0
x 0 x x x 0
x x 0 x x 0
x x x 0 x 0
x x x x 0 0
1 1 1 1 1 1
Truth Table for Six-input AND Evaluation
Input 1 Input 2 Input 3 Input 4 Input 5 Input 6 Output 1
0 x x x x x 0
x 0 x x x x 0
x x 0 x x x 0
x x x 0 x x 0
x x x x 0 x 0
x x x x x 0 0
1 1 1 1 1 1 1
