Publication 1752-UM001A-EN-P - October 2006
Set Up Your DeviceNet Network 39
SmartGuard 600 Controller Configuration Signature
The configuration signature is read during each browse and whenever
the Device Properties dialog is launched while the software is in the
Online mode. RSNetWorx for DeviceNet software compares the
configuration signature in the software (offline) device configuration
file to the configuration signature in the online device. If the
configuration signatures do not match, you are prompted to upload
the online device configuration or download the software device
configuration to resolve the mismatch.
Safety Reset (Optional)
If you need to reset the safety device’s attributes to the out-of-box
default state, you can do so via the Reset Safety Device dialog.
You can reset the attributes shown on the Reset Safety Device dialog
by checking their associated checkbox. Leaving an attribute checkbox
blank preserves that attribute’s setting during the safety reset
operation.
