Create Your Application Program 89
Create a Function Block
Program
To create a program using function blocks, you create connections
from the function block to input and output tags.
Add an Input or Output Tag
Follow these steps to add a tag.
1. Click the Input or Output tab in the object list.
2. Select the tag you want to use, and drag and drop it into
position on the workspace.
You can select multiple I/O tags and position them at the same
time.
Place Input Tags
Add a Function Block
Follow these steps to add a function block to the workspace.
1. Click the Function Block tab in the object list.
2. Select the function block you want to use, and drag and drop it
into position on the workspace.
TIP
Input and output tags that are used in the application program
appear bolded in the object list.
