GREASE LUBRICATION
WARNING
O Before lubricating the machine, be sure to
set the MODE keyswitch at “
” to lock the
table.
O When stepping onto the table for
performing maintenance, wear a helmet
and safety shoes, and take care not to
slip.
Check the grease lubrication condition of the following parts every
month, and add grease to them as required.
Recommended greases: Esso Lithtan 2
Mobil Mobilux 2
Shell Alvania Grease 2
NOTICE
O Apply grease to the grease nipples with a grease gun. Take care not to
apply grease in an excessive amount.
ڈ
1
Saw blade tension slides
ڈ
2
Driven wheel bearing
ڈ
3
Backgauge screw (option)
1
NOTE
O Remove the driven wheel
rear cover to check and
lubricate the saw blade
tension slides. The cover is
secured with eight screws.
