Amada vm2500 - Machine Specifications

I-7
Machine
VM1200 VM2500
Throat (width),
mm {in.}
508 {20.0}
Height,
mm {in.}
508 {20.0}
Cutting
capacity
Length,
mm {in.}
1219 {48.0} 2515 {99.0}
Width,
mm {in.}
41 {1.61}
Thickness,
mm {in.}
1.3 {0.051}
Length,
mm {in.}
4670 {183.8}
Running speed,
m/min {fpm}
10 to 90 {32.8 to 295.3}
Saw blade
Tension Automatic hydraulic tension control
Side Cemented carbide inserts and hydraulic clamps
Saw blade
guides
Back Cemented carbide backup tips
Main table
width, mm {in.}
547 {21.5}
Sub-table
width, mm {in.}
508 {20.0}
Length, mm {in.} 1640 {64.6} 3095 {121.8}
Stroke, mm {in.} 1250 {49.2} 2550 {100.4}
Allowable load
capacity, kg {lb}
2000 {4410} 5000 {11025}
Height from
floor, mm {in.}
1005 {39.6}
T-slot, mm {in.} 18 {0.71} (for M16)
Table
Feed control AC servo motor
