IV-21
Ending cutting
A
UTOMATIC STOP
Relative coordinate system
When cutting proceeds and the value shown in the field at the right of
the PB field reaches the value shown in the PB field, the cutting feed
stops. After 30 sec, the machine totally stops.
Absolute coordinate system
The cutting feed stops when the table move distance reaches the work
length (L) shown in the L field. After 30 sec, the machine totally stops.
RETURNING TABLE
Return the table to near the cutting start position or to the backward
end by either of the following procedures.
Rapidly moving table backward
1 Press and hold the TABLE BACKWARD button.
The table moves backward rapidly.
Moving table backward at low speed
1 As required, press and illuminate the TABLE SPEED CHANGE
button to change to low speed.
2 Press and hold the TABLE BACKWARD button to move the table
fully backward.
CAUTION
O Depending on the clamp condition or
internal stress of the work, the cut slot
may be narrowed or bent. When moving
the table backward, check that the saw
blade is not subjected to undue force.
After the work is completely cut off, it is
safe to remove the cut piece first.
