Amada vm2500 - Specifications and Dimensions

I-4
3200 {125.98}
1219 {48.00}
66 {2.60}
1640 {64.57}
1684 {66.30}
1640 {64.57}
BACKGAUGE
(OPTION)
TABLE SURFACE
3263 {128.46}
1702 {67.01}
CHIP CONVEYOR
(OPTION)
2020 {79.53}
469
{18.46}
750 {29.53}
1250 {49.21}
41
{1.61}
25
{1.57}
155
{6.1}
32
{1.26}
18 {0.71}
508
{20.00}
547 {21.54}
520 {20.47}
508 {20.00}
508 {20.00}
556 {21.89}
2450 {96.46}
3040 {119.69}
1005 {39.57}
131
{5.16}
425 {16.73}
(UPPER SAW BLADE GUIDE STROKE)
(MAXIMUM WORK
THROAT)
(MAXIMUM WORK HEIGHT)
(T-SLOT NOMINAL SIZE)
(BACKGAUGE
STROKE)
218
{8.58}
1579 {62.17}
SAW BLADE
RUNNING
LINE
SAW BLADE BACK POSITION
SIGNAL TOWER
(OPTION)
SAW BLADE
BACK POSITION
1119 {44.06}
1999 {78.70}
1054 {41.50}
1407 {55.39}
(SUB-TABLE)
(MAIN TABLE)
(MAXIMUM WORK LENGTH)
FLOOR SURFACE
(TABLE STROKE)
Unit: mm {in.}
RUNOUT
DETECTOR
(OPTION)
LASER BEAM
UNIT (OPTION)
SPECIFICATIONS
Dimensions of main parts
VM1200
