II-2
LOCATION
S
elect such a location that ample space can be provided around the
machine for loading workpieces, unloading cut pieces, and performing
maintenance on the machine.
NOTICE
O Select a location where the machine will not be exposed to rain and wind. If
another machine located nearby produces vibration or dust, take necessary
measures against the vibration or dust.
FOUNDATION
Install the machine on a level and flat concrete floor. Execute the
foundation work by yourself. The positions of leveling bolts and
anchor bolts are as shown in the foundation drawing below.
NOTICE
O The load that bears on one leveling bolt is a maximum of 12000 kg {26460
lb}.
O A minimum pressure of 2.9 MPa {421 psi} is applied to the concrete around
the leveling bolts.
O Hold the flatness of the concrete floor within 10 mm {0.4 in.}.
NOTE
O The alternate long and two short dashes lines in the foundation drawing show
the outline of the machine.
