RUNOUT DETECTOR
T
he runout detector senses
the runout of the saw blade
during cutting and
automatically stops the
machine when the actual
runout of the saw blade
exceeds the preset runout
tolerance.
A roller that detects the
runout of the saw blade is
installed in the upper saw
blade guide.
Detection roller
Setting runout tolerance
Set the runout tolerance on the DEVIATION display as described
below.
At a certain time after the runout of the saw blade exceeds the preset
tolerance, the machine automatically stops. The setting range is 0.0 to
±9.9 mm {0.0 to ±0.389 in.}.
1 Press the DEVIATION
button to go to the
DEVIATION display.
