Amada vm2500 - List of Cutting Operations

IV-24
LIST OF CUTTING OPERATIONS
G
eneral flow of cutting operations
1 Turn POWER switch to
ON
······· Turn POWER switch to ON to illuminate POWER ON
light.
When error occurs, error
message is shown on touch
screen
······· Remove cause of error.
Refer to “Error list” later in this Part.
2 Press HYDRAULIC ON
button
······· Press and illuminate HYDRAULIC ON button to start
hydraulic pump motor.
3 Zero-return upper saw
blade guide and
backgauge (option)
······· Press ZERO-RETURN button.
Upper saw blade guide rises to upper end, and
backgauge (option) zero-returns.
MENU display is shown on touch screen.
4 Register saw blade type
and tooth pitch
······· Press BLADE button on MENU display to go to BLADE
display.
Select saw blade type and tooth pitch of saw blade.
5 MENU display ψ
PROGRAM display
Select CNC input or
manual input
······· Press AUTO CUT CONDIT button (CNC input) or
MANUAL CUT CONDIT button (manual input).
