IV-25
6 Set work data, saw blade
r
unning speed, and
cutting rate
·······
CNC INPUT display
Press DIMENT button to enter work length (L) and
height (H) in L and H fields.
Press QUAL. MAT button to show standards by
countries, and select standard and material type of work
to be cut. Saw blade running speed and cutting rate
are automatically set and shown in V and R fields
respectively.
MANUAL INPUT display
Press V field to open numeric keypad, and enter
desired saw blade running speed.
Press R (or VT) field to open numeric keypad, and enter
desired cutting rate (or table feed speed).
7 Set runout tolerance
(when using optional
runout detector)
······· Press DEVIATION button to go to DEVIATION display,
and press RUNOUT DETECTOR ON/OFF button to
show ON on button.
Press TOLERANCE field to open numeric keypad, and
enter runout tolerance.
8 Position work
·······
Laser beam unit (option)
Press LASER BEAM ON button (option) to turn on laser
beam. (Laser beam automatically turns off 5 min
later.)
Position work by aligning scribed line of work with laser
beam.
Backgauge (option)
Enter target position on BACKGAUGE display, and
simultaneously press BACKGAUGE button and
CONFIRMATION button.
Backgauge starts to move to target position.
Gently push work against backgauge by using crane or
forklift. After work positioning, zero-return backgauge.
Cut-to-width stoppers (option)
Install stoppers on table.
Push work against stoppers to position it.
9 Clamp work
······· Clamp work with fixtures.
10 Approach
······· Press and hold TABLE FORWARD button to bring work
close to saw blade.
11 Start saw blade
······· Press BLADE START button to start saw blade and turn
on cutting fluid.
