I-5
VM2500
2515 {99.00}
70 {2.76}
3095 {121.85}
5800 {228.35}
2984 {117.48}
2940 {115.75}
BACKGAUGE
(OPTION)
TABLE SURFACE
5863 {230.83}
1702 {67.01}
CHIP CONVEYOR
(OPTION)
2020 {79.53}
1117 {43.98} 1398 {55.04}
2550 {100.39}
41
{1.61}
29 {1.14}
155
{6.1}
32
{1.26}
18 {0.71}
508 {20.00}
547 {21.54}
520 {20.47}
508 {20.00}
508 {20.00}
556 {21.89}
2450 {96.46}
3040 {119.69}
1005 {39.57}
131
{5.16}
425 {16.73}
(UPPER SAW BLADE GUIDE STROKE)
(MAXIMUM WORK THROAT)
(MAXIMUM WORK HEIGHT)
(T-SLOT NOMINAL SIZE)
(BACKGAUGE
STROKE)
218
{8.58}
2879 {113.35}
SAW BLADE RUNNING LINE
LASER BEAM UNIT(OPTION)
RUNOUT
DETECTOR
(OPTION)
1999 {78.70}
1119 {44.06} 1054 {41.50}
2707 {106.57}
(SUB-TABLE)
(MAIN TABLE)
(MAXIMUM WORK LENGTH)
FLOOR SURFACE
(TABLE STROKE)
Unit: mm {in.}
SIGNAL TOWER
(OPTION)
SAW BLADE BACK POSITION
SAW BLADE BACK POSITION
