Carrying with crane
WARNING
٨ Four JIS No. 4, 6u24 wire ropes, 22.4 mm
in diameter and 4129 mm or more in
length, are required to lift the machine.
Take care so that the wire ropes do not
touch the table.
The mass of the machine is as follows:
VM1200: 3300 kg {7277 lb}
VM2500: 5500 kg {12128 lb}
٨
Keep the sling angle of the wire ropes at
80q or less.
1
A
ttach the shackles to
the four lifting lugs
(positions A).
A A
A A
2 Pass the wire ropes
through the shackles,
and secure the
shackles.
3 While balancing the
machine, slowly lift it
with the crane.
SLING ANGLE
OF 80 OR LESS
