180 Sequoia Series
Bit
Signal
Meaning
Operation Status Group
0
CAL
Interface complete its calibration cycle
3
TRANS
Transient is completed
4
MEAS
Measurement is completed
Questionable and Questionable Instrument Isummary Status Groups
0
OV
Output voltage faulted, output voltage differ from program
value
1
OCP
The overcurrent protection circuit has tripped
3
TO
An overtemperature condition has occurred
9
RI
The remote shut down state is active
12
Clrms
The rms current limit circuit is active
14
n/a
Standard Event Status Group
0
OPC
Operation complete
2
QYE
Query error
3
DDE
Device-dependent error
4
EXE
Execution error
5
CME
Command error
7
PON
Power-on
Status Byte and Service Request Enable Registers
3
QUES
Questionable status summary bit
4
MAV
Message Available summary bit
5
ESB
Event Status Summary bit
6
MSS
Master Status Summary bit
RQS
Request Service bit
7
OPER
Operation status summary bit
Table 7-2: Configuration of Status Register
