Sequoia Series 67
4.10 Output Subsystem
This subsystem controls the main outputs, the signal outputs and the output impedance (with
impedance option) of the power source.
Subsystem Syntax
OUTPut
[:STATe] <bool> Enable/disable output voltage, current, power, etc.
:DFI
[:STATE] <bool> Enable/disable DFI output
:SOURce <source> Selects an event source
(QUES|OPER|ESB|RQS|OFF)
:PON
[:STATe] RST | RCL0
:PROTection
:CLEar Reset latched protection
:RI
[:LEVel] LOW | HIGH Sets Remote Inhibit input level mode.
:MODE <mode> set remote inhibit input (LATC|LIVE|OFF)
:STATus? Query only, return the status of the RI
:TTLTrg
:MODE TRIG | FSTR Sets or disabled Function strobe mode.
[:STATe] <bool> Enable/disable trigger out drive
:SOURce <source> Selects a TTLTrg source (BOT|EOT|LIST)
4.10.1 Output Relay
OUTPut[:STATe]
This command enables or disables the source output. The state of a disabled output is an output
voltage amplitude set to 0 volts, with output relays opened. The query form returns the output state.
Note: On three phase Sequoia Series with firmware revision below 0.31, it is recommended to set the
phase coupling to ALL before closing the output relay to ensure all phases are correctly programmed.
E.g. “inst:coup all:;outp 1”.
Command Syntax OUTPut[:STATe]<bool>
Parameters 0 | OFF | 1 | ON
*RST Value OFF
Examples OUTP 1 OUTP:STAT ON
Query Syntax OUTPut[:STATe]?
Returned Parameters 0 | 1
Related Commands VOLT:RANGE
OUTPut:DFI
This command enables or disables the discrete fault indicator (DFI) signal to the Lx\Ls Series. The
DFI is an active high open collector output with internal pull up to 5Vdc. The pull up can be removed
by removing W1 on the 7004-716 range/relay board.
