Ametek SEQUOIA Series - Mil-Std 704 E (-704)

208 Sequoia Series
8.5 MIL-STD 704E (-704)
MIL-STD 704 tests for revisions D and E only can be executed remotely from the GPIB or RS232 using
the following command tree.
MIL-STD 704 tests for revisions A, B, C and F are implemented only through the Sequoia Virtual
Panels Windows software provided with each power source. As such, there are no SCPI commands
that apply to these revisions of MIL-STD 704 and they cannot be executed from the front panel. See
the Avionics Software Manual (P/N 4994-971) for more details on performing tests to these revisions
of the standard.
This capability requires the presence of the –704 option.
8.5.1 AC System
:MIL704
:VERSion D|E
:SSTate
:VOLT
[:LEVel]
:MODulation
:UNBalance
:PHASe
[:DIFFerence]
:WAVeform
[:DISTortion]
:FREQuency
[:LEVel]
:MODulation
:TRANsient
:VOLTage
[:LOW]
:HIGH
:FREQuency
[:LOW]
:HIGH
:ABNormal
:VOLTage
[:UNDer]
:OVER
:FREQuency
[:UNDer]
:OVER
:EMERgency
:VOLTage
:FREQuency
