4.27 Status Subsystem Commands
This subsystem programs the power source status registers. There are four groups of status registers;
• Operation Status Group
• Questionable Status Group
• Questionable Instrument ISummary Group
• Standard Event Group
The Standard Event group is programmed with Common commands. The Operation, Questionable,
and Instrument ISummary status groups each consist of the following three registers:
Condition
Enable
Event
Refer to chapter 7 for more information about the status registers.
Subsystem Syntax
STATus
:OPERation
:EVENt Returns the value of the event register
:CONDition Returns the value of the condition register
:ENABle <n> Enables specific bits in the Event register
:QUEStionable
:EVENt Returns the value of the event register
:CONDition Returns the value of the condition register
:ENABle <n> Enables specific bits in the Event register
:INSTruments
:ISUMmary
:EVENt Returns the selected phase’s event register value
:CONDition Returns the selected phase’s condition register
:ENABle Enable specific bits in selected phase’s Event
register values
Bit Configuration of Status Operation Registers
Bit Position
15-5
4
3
1-2
0
Bit Name
not used
MEAS
TRANS
not used
CAL
Bit Weight
16
8
1
CAL Calibration is completed
TRANS Transient is completed
MEAS Measurement is completed
