Firmware Upgrade & Info for Network Admin
164
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
2. Select the Connections tab.
3. Click LAN Settings.
The Local Area Network (LAN) Settings dialog box opens.
If the Proxy server box is checked, go to Step 4.
If the Proxy server box is not checked, check it before going to Step 4.
4. Click Advanced.
The Proxy Settings dialog box opens.
5. In the Exceptions field, enter the appropriate IP address for the Enova DGX Switcher (see page 52).
6. Click OK to exit each of the dialog boxes used in these steps.
Connections tab
LAN Settings button
Be sure Proxy server box is checked
Enter Enova DGX Switcher’s IP address
