Appendix D – Programmer’s Interface for System Diagnostics
215
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
FIG. 120 Display for v1i7 (verbosity 1, component 7)
FIG. 121 Display for v2i7 (verbosity 2, component 7)
FIG. 122 Display for v3i6 (verbosity 3, component 6)
~scrv1i7!
[7:System Sensors] detected
[io board 1 sensors] detected
[io board 2 sensors] detected
[io board 5 sensors] detected
[io board 8 sensors] detected
[center board 1 sensors] detected
[signal sense]
[fan controller 1] detected
~scrv2i7!
[7:System Sensors] detected
[io board 1 sensors] detected
[temp 1] 25.0c
[io board 2 sensors] detected
[temp 1] 25.0c
[io board 5 sensors] detected
[temp 1] 26.0c
[io board 8 sensors] detected
[temp 1] 26.0c
[center board 1 sensors] detected
[temp 1] 26.0c
[signal sense]
~scrv3i6!
[6:Power System] good
[status flags] 0x0001
[available system power] 936w
[required system power] 236w
[ac power slot 1] good
[status flags] 0x00
[available power] 936w
[output power] 120.31w
[voltage] 12.031v
[current] 10.000a
[fan speed] 5000 rpm
[service hours] xxx
[model#] CAR08112FPBXZ01A
