Enova DGX HDMI Boards
73
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
EDID Resolutions Supported through Local DDC
Standard and established timings are given in the tables following along with detailed timing blocks.
Important: The EDID can be re-programmed to support additional resolutions through the local DDC using
the EDID programming functionality in the DGX Configuration Software (see page 181).
Standard Timings (Default Shipping EDID*)
* The default EDID can be overwritten to include a broad range of features, including HDMI mode, based on installation
requirements.
** This is the preferred timing identified in the EDID.
Established Timings
AMX reserves the right to modify its products and their specifications without notice.
Tip: If you are experiencing audio problems, it may be because you are trying to pass Dolby or DTS or high
PCM frequency rates and the destination device does not support them. If you are experiencing video
problems, it may be because you are trying to pass a video format that the destination device does not
support. In either of these cases, re-programming the EDID may help resolve the problem.
Resolution Refresh Rate Max.
1920x1080** 60 Hz
1920x1200 60 Hz
1680x1050 60 Hz
1600x1200 60 Hz
1600x900 60 Hz
1400x1050 60 Hz
1440x900 60 Hz
1360x765 60 Hz
1280x1024 60 Hz
1280x900 60 Hz
1280x800 60 Hz
1280x720 60 Hz
Resolution Refresh Rate
1280x1024 75 Hz
1152x870 75 Hz
1024x768 60 Hz, 70 Hz, 75 Hz, 87 Hz
832x624 75 Hz
800x600 56 HZ, 60 Hz, 72 Hz, 75 Hz
720x400 70 Hz, 88 Hz
640x480 60 Hz, 67 Hz, 72 Hz, 75 Hz
