LEGEND
C,C1,,, Condenser
EU,EU1,EU2 Humidifi
er solenoid
EA Steam (condensation) chiller solenoid
EL Wash solenoid
ED Elettrovalvola detergente
EVG Chamber burner solenoid
FM1,FM2 Motor thermal protection (built-in)
FU1,FU2… Fuse
FLC EMC line fi lter
FR1,FR2… Cooling fan motor
FS1 Chamber safety thermostat
INV Motor inverter
K0 Inverter line relay
KFS Power line auxiliary contactor
Keyboard Interface board
KR1/3,…. Chamber heating element contactor
L1, L2 Chamber light bulb
M1, M2.. Motor
MV Humidity venting valve
PA Water pressure switch
PFC PFC for EMC
PD Detergent Pump
R1,R2…. Heating elements
S0 Main switch
SC Chamber probe
SCHF Oven control circuit board
SP Door microswitch
SS Pin probe
SU1, SU2 Humidity control probe
TR1 Transformer 230V/12V, 12VA - 5VA
TR2,TR3 Transformer 230V/24V AC
TRAL Chamber light transformer 230V/12V AC
X./.. Connector
