4.2 Setting Parameters
4-15
(2) Measurement repetition setting
This setting is valid when the measurement method is set to “Time”
or “Count.” Specify whether to repeat measurement for the speci-
fied time (when “Time” is selected) or the specified number of bits
(when “Count” is selected).
Select “Repeat” on the measurement menu screen to perform setting.
<Procedure>
1. Select “Repeat” by using the
and
keys on the
Measure* setting screen.
2. Press [Enter] or
to display the Repeat setting items.
3. Select whether to repeat measurement (On) or perform meas-
urement once and finish (Off) by using the
and
keys.
Press [Enter] to finalize the setting.
When this setting is performed during measurement, meas-
urement is restarted and the menu closes. When this setting is
performed while measurement is stopped, the measurement
menu is displayed again.
(3) Measured results display setting
Specify whether to display measured results in real time (Current)
or display the measured result of the last interval (Last). When
“Last” is selected, the measured results display is not updated until
measurement in the current interval is complete. If measurement
is stopped manually by the user, the measured result in this case is
the same as that when “Current” is selected.
Select “Select” on the measurement menu screen to perform setting.
<Procedure>
1. Select “Select” by using the
and
keys on the Meas-
ure* setting screen.
2. Press [Enter] or
to display the Select setting items.
3. Select whether to display measured results in real time (Cur-
rent) or display the measured result of the last interval by using
the
and
keys. Press [Enter] to finalize the setting.
To Next Page
