(2) Data polarity setting
Set data polarity.
Select “Data” on the NRZ input menu screen to perform setting.
<Procedure>
1. Select “Data” by using the
and
keys on the NRZ
Input* setting screen.
2. Press [Enter] or
to display the Data setting items.
3. Select data polarity by using the
and
keys. Press
[Enter] to finalize the setting.
When this setting is performed during NRZ measurement,
measurement is restarted and the menu closes. When this
setting is performed while measurement is stopped or during
DVB-SPI or DVB-ASI measurement, the NRZ input menu is
displayed again.
(3) Clock polarity setting
Set clock polarity. Refer to Appendix A “Specifications” on phase
relationships.
Select “Clock” on the NRZ input menu screen to perform setting.
<Procedure>
1. Select “Clock” by using the
and
keys on the NRZ
Input* setting screen.
2. Press [Enter] or
to display the Clock setting items.
3. Select clock polarity by using the
and
keys. Press
[Enter] to finalize the setting.
When this setting is performed during NRZ measurement,
measurement is restarted and the menu closes. When this
setting is performed while measurement is stopped or during
DVB-SPI or DVB-ASI measurement, the NRZ input menu is
displayed again.
