4.2 Setting Parameters
4-25
(4) Enable function setting
Set enable polarity or enables/disables its use. When this function
is set to Positive, clock and data are enabled if level is High. When
set to Negative, they are enabled if level is Low. They are enabled
regardless of the set level if this function is set to Off.
Select “Enable” on the NRZ input menu screen to perform setting.
<Procedure>
1. Select “Enable” by using the
and
keys on the NRZ
Input* setting screen.
2. Press [Enter] or
to display the Enable setting items.
3. Select enable polarity or its use On/Off by using the
and
keys. Press [Enter] to finalize the setting.
When this setting is performed during NRZ measurement,
measurement is restarted and the menu closes. When this
setting is performed while measurement is stopped or during
DVB-SPI or DVB-ASI measurement, the NRZ input menu is
displayed again.
(5) Termination resistor setting
Set termination resistor value.
Select “Termination” on the NRZ input menu screen to perform set-
ting.
<Procedure>
1. Select “Termination” by using the
and
keys on the
NRZ Input* setting screen.
2. Press [Enter] or
to display the Termination setting items.
3. Select termination resistor value by using the
and
keys. Press [Enter] to finalize the setting.
When this setting is performed during NRZ measurement,
measurement is restarted and the menu closes. When this
setting is performed while measurement is stopped or during
DVB-SPI or DVB-ASI measurement, the NRZ input menu is
displayed again.
To Next Page
