Section 4 Operation
4-28
(2) Packet setting
Set packet type used for input/output. Packets (measurement tar-
get part) available for the MP8931A are shown in the figure below.
Note that data (PID, 16 valid extra bytes etc.) except the measure-
ment target part is fixed to High level for output, and not compared
for input.
1 byte
(47 h)
187 bytes
(PN pattern)
16
bytes
[1] When 187 bytes of 204-byte packet are measurement targets
1 byte
(47 h)
187 bytes
(PN pattern)
[2] When 187 bytes of 188-byte packet are measurement targets
[3] When 184 bytes of 204-byte packet are measurement targets
1 byte
(47 h)
184 bytes
(PN pattern)
16
bytes
3 bytes
(PID)
[4] When 184 bytes of 188-byte packet are measurement targets
1 byte
(47 h)
184 bytes
(PN pattern)
3 bytes
(PID)
Measurement targets
1 byte
(47 h)
203 bytes
(PN pattern)
[5] When 203 bytes of 204-byte packet are measurement targets
[6] When 200 bytes of 204-byte packet are measurement targets
1 byte
(47 h)
200 bytes
(PN pattern)
3 bytes
(PID)
Fig. 4.2.12-1 Packet types
