4.2 Setting Parameters
4-29
Select “PKT” on the DVB-SPI menu screen to perform setting.
DVB-SPI Packet
204:(1)+187+(16)
204:(1)+187+(16)
188:(1)+187
204:(1+3)+184+(16)
188:(1+3)+184
204:(1)+203
204:(1+3)+200
<Procedure>
1. Select “PKT” by using the
and
keys on the
DVB-SPI* setting screen.
2. Press [Enter] or
to display the Packet setting items.
3. Select packet type used for input/output by using the
and
keys. Press [Enter] to finalize the setting.
When this setting is performed during DVB-SPI measurement,
measurement is restarted and the menu closes. When this
setting is performed while measurement is stopped or during
NRZ or DVB-ASI measurement, the DVB-SPI output menu is
displayed again.
