Ansul R-102 - Page 177

SECTION 9 – APPENDIX
UL EX3470 ULC EX3470
2014-SEP-01 REV. 11 PAGE 9-7
R-102 Restaurant Fire Suppression Manual
SYSTEM COMPONENT INDEX (Continued)
Part No.
Description
550122 Oval Sleeve Package
Includes: 100 Oval Sleeves
436063 Conduit Offset Shipping Assembly
Includes: 6 Conduit Offsets
78196 1/4 in. “Quik-Seal” Adaptor Package
Includes: 24 “Quik-Seals”
77285 3/8 in. “Quik-Seal” Adaptor Package
Includes: 24 “Quik-Seals”
77287 1/2 in. “Quik-Seal” Adaptor Package
Includes: 24 “Quik-Seals”
77289 3/4 in. “Quik-Seal” Adaptor Package
Includes: 24 “Quik-Seals”
79149 1/4 in. “Compression-Seal” Pipe Adaptor Package
Includes: 24 “Compression-Seals”
79151 3/8 in. “Compression-Seal” Pipe Adaptor Package
Includes: 24 “Compression-Seals”
79147 1/2 in. “Compression-Seal” Pipe Adaptor Package
Includes: 24 “Compression-Seals”
79153 1/2 in. “Compression-Seal” EMT Conduit Adaptor
Package
Includes: 24 “Compression-Seals”
423253 Hood Seal Adaptor Shipping Assembly
Includes: 6 Hood Seals
436228 Reducing Coupling
441042 Short Handle Cocking Lever with Lock Pin
(Mechanical/Electrical AUTOMAN)
441041 Long Handle Cocking Lever with Lock Pin
(Mechanical/Electrical AUTOMAN)
26310 Cocking Lever (AUTOMAN II-C)
416018 Cocking Lever (Mechanical Gas Valve)
438031 Lock Pin
13707 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Solenoid Valve – 3/4 in.
13708 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Solenoid Valve – 1 in.
550360 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Solenoid Valve – 1 1/4 in.
13709 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Solenoid Valve – 1 1/2 in.
13710 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Fluid Power Gas Valve – 2 in.
550363 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Fluid Power Gas Valve – 2 1/2 in.
17643 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Fluid Power Gas Valve – 3 in.
Part No. Description
426151 Gas Shut-off Equipment (Electrical 110 VAC, 60 Hz)
Includes: Relay – Manual Reset
423878 One Electric Switch (Field Mounted) Kit
Includes: Electric Switch (SPDT)
Mounting Hardware
423879 Two Electric Switch (Field Mounted) Kit
Includes: 2 Electric Switches (SPDT)
Mounting Hardware
423880 Three Electric Switch (Field Mounted) Kit
Includes: 3 Electric Switches (SPDT)
Mounting Hardware
423881 Four Electric Switch (Field Mounted) Kit
Includes: 4 Electric Switches (SPDT)
Mounting Hardware
428311 Alarm Initiating Switch Kit
55598 Gas Shut-off Equipment Mechanical (ANSUL)
Includes: Mechanical Gas Valve – 3/4 in.
55601 Gas Shut-off Equipment Mechanical (ANSUL)
Includes: Mechanical Gas Valve – 1 in.
55604 Gas Shut-off Equipment Mechanical (ANSUL)
Includes: Mechanical Gas Valve – 1 1/4 in.
55607 Gas Shut-off Equipment Mechanical (ANSUL)
Includes: Mechanical Gas Valve – 1 1/2 in.
55610 Gas Shut-off Equipment Mechanical (ANSUL)
Includes: Mechanical Gas Valve – 2 in.
25937 Gas Shut-off Equipment Mechanical (ASCO)
Includes: Mechanical Gas Valve – 2 1/2 in.
25938 Gas Shut-off Equipment Mechanical (ASCO)
Includes: Mechanical Gas Valve – 3 in.
15733 Gas Shut-off Equipment
Includes: Air Cylinder and Tube Assembly
434618 Remote Manual Pull Station Assembly
435960 Remote Manual Pull Station Assembly
Includes: 50 ft (15.2 m) of Wire Rope
24915 Break Rod Package
Includes: 10 Glass Break Rods (Part No. 4834)
(Replacement)
427074 Trim Rings (Pack of 10)
434525 Flexible Conduit – 500 ft (152.4 m)
435959 Flexible Conduit – 500 ft (152.4 m)
Includes: 500 ft (152.4 m) of Wire Rope
435979 Flexible Conduit Strain Relief
Includes: 50 Strain Reliefs
434347 Flexible Conduit Inserts
Includes: 50 Inserts
