SECTION 5 – INSTALLATION INSTRUCTIONS
UL EX3470 ULC EX3470
2014-SEP-01 REV. 11 PAGE 5-33
R-102 Restaurant Fire Suppression Manual
INSTALLATION OF REMOTE MANUAL PULL STATION OR
MECHANICAL GAS VALVE UTILIZING FLEXIBLE CONDUIT
(Continued)
Flexible Conduit Splicing (Allowed on Pull Station
Installations Only) (Continued)
10. Tighten strain relief into compression union. See Figure
5-106.
FIGURE 5-106
008057
11. Push flexible conduit into strain relief until it is approximately
1/16 in. (1.6 mm) from the bottom of the flexible conduit
insert, then tighten strain relief nut onto strain relief body.
See Figure 5-107.
FIGURE 5-107
008058
12. Complete the remainder of the flexible conduit and wire
rope installation to the pull station or the gas valve.
Component Removal Instructions
REMOVAL OF BLOCK
Using thumbs on the clips on each side of the block, press firmly in
the direction of the center of the block, at the same time pressing
in a slightly downward direction. As the clips on the side of the
block release from the pull station cover, the block will release
and be free to be removed from the backside of the cover. See
Figure 5-108.
FIGURE 5-108
007884
REMOVAL OF PULL KNOB
Insert a small screwdriver into slot at bottom of pull knob. Push
slightly on the screwdriver and turn pull knob clockwise, then
pull knob can be removed without breaking the glass rod. See
Figure 5-109.
FIGURE 5-109
008059
REMOVAL OF PULL CAP
Using a small screwdriver or other blunt object, push on the back-
side of the pull cap. This will free the cap from the pull knob. See
Figure 5-110.
FIGURE 5-110
008060
