SECTION 9 – APPENDIX
UL EX3470 ULC EX3470
2014-SEP-01 REV. 11 PAGE 9-1
R-102 Restaurant Fire Suppression Manual
SYSTEM SELECTION GUIDE
Note: System options do not cover all conceivable/acceptable variations. They are listed here as a general guideline to show
the most common type arrangement for multiple systems. Based on certain system designs utilizing manifolding, non-manifolding,
3-tank systems, etc., other tank/cartridge combinations can be designed. The combinations below are based on 11 flow, 3 gallon tanks
and 5 flow, 1.5 gallon tanks. More competitive designs may be available by utilizing 12 flow and 6 flow systems when appropriate.
Total Tank Type of Carbon Dioxide Nitrogen
Flow No.* Quantity System Type of Hardware Cartridge Required Cartridge Required
1-5 1 Single 1.5 Gal. Reg. Release 101-10 (423439) LT-20-R (423429)
6-11 1 Single 3 Gal. Reg. Release 101-20 (423441) LT-30-R (423435)
12-16 2 Double 1.5 Gal. Reg. Release 101-30 (423443) Double (423493)
3 Gal. Additional Tank
17-22 2 Double 3 Gal. Reg. Release 101-30 (423443)** Double (423493)
3 Gal. Additional Tank
17-22 2 Manifold 3 Gal. Reg. Release — Double (423493)
3 Gal. Additional Tank
23-27 3 Multiple 1.5 Gal. Reg. Release 101-10 (423439) LT-20-R (423429)
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
23-33 3 Multiple 3 Gal. Reg. Release 101-20 (423441) LT-30-R (423435)
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
23-33 3 Multiple 3 Gal. Reg. Release N/A Double (423493)
(Optional) (2) 3 Gal. Additional Tanks
34-38 4 Multiple 1.5 Gal. Reg. Release 101-10 (423439) LT-20-R (423435)
3 Gal. Reg. Actuator N/A LT-A-101-30 (423491)
Double 3 Gal. Tank Box
34-38 4 Multiple 1.5 Gal. Reg. Release 101-30 (423443) Double (423493)
(Optional) 3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
39-44 4 Multiple 3 Gal. Reg. Release 101-20 (423441) LT-30-R (423435)
3 Gal. Reg. Actuator N/A LT-A-101-30 (423491)
Double 3 Gal. Tank Box
39-44 4 Multiple 3 Gal. Reg. Release 101-30 (423443)** Double (423493)
(Optional) 3 Gal. Additional Tank
3 Gal. Reg. Actuator 101-30 (423443)*** LT-A-101-30 (423491)
3 Gal. Additional Tank
45-49 5 Multiple 1.5 Gal. Reg. Release 101-30 (423443) Double (423493)
3 Gal. Additional Tank
3 Gal. Reg. Actuator N/A LT-A-101-30 (423491)
Double 3 Gal. Tank Box
* Based on 5 flow numbers for a 1.5 gal system and 11 flow numbers for a 3 gal. system.
** If tanks are manifolded, only a “double tank” nitrogen cartridge (Part No. 423493) can be used.
*** If tanks are manifolded, either an LT-A-101-30 nitrogen cartridge (Part No. 423491) or a double tank cartridge (Part No. 423493) can be used.
