A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
2.3. DENTAL CHAIR
Description of the parts.
a Headrest.
b Backrest.
c Fixed armrest.
d Removable armrest (optional).
e Stop foot board.
ANTHOS A1.3, ANTHOS A2.5, ANTHOS A2.7 and ANTHOS A1.3 L
model dental chairs
Operating time.
The operating and rest times are as follows:
work 25 sec. - rest 10 min.
Maximum permitted load.
• Maximum permissible load on the dental chair: see DATA SPECIFICATIONS.
• Maximum load supported by armrest: 68 kg.
Do not exceed these values.
CRUSHING HAZARD
Despite the presence of safety systems to prevent crushing, there is always a minimum residual risk due to moving parts.
The positions already stored ensure a safety distance between dental chair and floor.
Do not store lower dental chair positions, and in any case pay attention to the risk of crushing.
ANTHOS A1.3, ANTHOS A2.5, ANTHOS A2.7 and ANTHOS A1.3 L
model dental chairs
