A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
5.1.4. PROGRAMMING THE DENTAL CHAIR POSITIONS A, B, C and D
This setting is specific for each single operator.
Proceed as follows:
• Adjust the dental chair into the desired position with the manual
movement buttons (L, M, N, O).
• Hold button (R) for at least 2 seconds to activate save mode.
The position of the dentist’s board is not stored in dental chair
programmes.
• Press the button (L), (M), (N) or (O) briefly to assign the position to the
button.
The appearance of icon (A) relating to the selected programme on the
LCD Touch DISPLAY will confirm that it has been saved.
To recall a programmed position, shortly press the button of the
selected programme.
CRUSHING HAZARD
The positions already stored ensure a safety distance
between dental chair and floor. Do not store lower dental
chair positions, and in any case pay attention to the risk of
crushing.
The button (P) can be used in the event of an emergency to move the
patient into the Trendelenburg position.
• The Trendelenburg position is already set and cannot be
changed
• For L6 model:
the emergency position is not activated if the bowl is in the
interference area (see paragraph 4.1).
5.1.6. TURNING ON THE OPERATING LIGHT
Press the button (G) to turn on/off the operating light.
Light brightness adjustment.
VENUS PLUS, VENUS PLUS -L version, VENUS PLUS MCT version
lights only.
• Press and hold button (G) (at least 2 seconds).
If the light is off, it will be turned on before accessing the
adjustment menu.
• Adjust beam brightness by pressing “increase” or “decrease” buttons.
Value setting range: 1 to 10.
• Press button (G) again to confirm the selected brightness.
