Anthos A3 Plus - Instruments on Assistants Board

A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
72
EN
6.2. INSTRUMENTS ON ASSISTANT’S BOARD
All the instruments applied to the assistant's board maintain the same
operation as those on the dentist's board.
In particular:
• Syringe, see paragraph 5.3.
• Turbine, see paragraph 5.4.
• Micromotor, see paragraph 5.5.
• Scaler, see paragraph 5.6.
• Curing light, see paragraph 5.7.
• Camera, see paragraph 5.8.
The turbine, micromotor and scaler have a cock (f) for adjusting
the spray water, under the assistant's board.
It is not possible to adjust the amount of spray air in the turbine
and micromotor.
Instruments on IDRICO SINGOLO assistant’s board.
The applicable instruments are as follows:
• Syringe, see paragraph 5.3.
• Turbine, see paragraph 5.4.1.
• Micromotor, see paragraph 5.5.3.
• Scaler, see paragraph 5.6.1.
• Curing light, see paragraph 5.7.
• Camera, see paragraph 5.8.2.
