A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
5.1.1.2. STOPWATCH (LCD Touch console only)
• Press the button (C) to access the STOPWATCH function:
Stopwatch setting
The countdown can be set from a minimum of 10 seconds to a
maximum of 10 minutes.
• Set the time using the buttons "+" and "-".
• Press the "PLAY" button (A) to start the countdown.
• Press the "PAUSE" button (A1) to stop the countdown.
• At this point, you can press the “PLAY” button (A) to restart the
countdown or button “-” (U) to stop the countdown and return to the
time setting stage.
Once the set time has elapsed, the dental unit emits an intermittent
sound.
• Press the “-” button (U) to stop the sound and select the last time value
set in the timer.
5.1.2. OPERATOR SELECTION (LCD Touch console only)
• Press the button (B) repeatedly to set the desired operator.
There are 4 selectable operators.
5.1.3. DENTAL CHAIR "RINSING POSITION" AND "RESET POSITION" PROGRAMMING
This setting is specific for each single operator.
Proceed as follows:
• Adjust the dental chair into the desired position with the manual
movement buttons (L, M, N, O).
• Hold button (R) for at least 2 seconds to activate save mode.
for L6 model:
In the Rinse Position, the maximum seat height that can be
saved is the safety height (no interference between the seat
and the bowl).
• Press the buttons "Reset Position" (patient entry/exit) (M) or "Rinse
Position" (K) briefly to assign the position to the button.
The "Rinse Position" button (K) moves backrest and seat to
rinse position.
When button (K) is pressed again, backrest and seat will go
back to the previous position.
CRUSHING HAZARD
The positions already stored ensure a safety distance
between dental chair and floor. Do not store lower dental
chair positions, and in any case pay attention to the risk of
crushing.
