A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
6. ASSISTANT’S BOARD OPERATION
Description of the parts.
a Assistant’s board: it can hold 2 suction tubes and 3 instruments, of which 1 is dynamic.
b Control panel used to operate the dental chair and water unit.
c Guides with sliding rollers that hold up the hoses of the suction tubes.
d Articulated arm allowing positioning the assistant’s board in the area most convenient for the operator.
The arm is equipped with a safety device that stops dental chair movement as soon as it detects an obstacle.
e Pair of articulated arms allowing positioning the assistant’s board in the area most convenient for the operator.
The two arms are equipped with a safety device that stops dental chair movement as soon as it detects an obstacle.
f Pantograph arm with six work positions, allowing a vertical stroke of the assistant's board of 300 mm.
To move the pantograph arm back to the fully lowered position, lift it until reaching the end of travel and then lower it.
g Clutched pantograph arm, with vertical stroke of the assistant's board of 300 mm.
h IDRICO SINGOLO assistant’s board: it can hold 2 suction tubes and 3 instruments, 2 of which dynamic.
i IDRICO SINGOLO control panel to control the functions of the dental chair, the water unit and the instruments housed on the assistant’s board.
Dental units model:
A3 PLUS CONTINENTAL
A3 PLUS INTERNATIONAL
A5 CONTINENTAL
A5 INTERNATIONAL
A5 CART
Dental units model:
A3 PLUS CONTINENTAL
A3 PLUS INTERNATIONAL
A5 CONTINENTAL
A5 INTERNATIONAL
A5 CART
Dental units model:
A5 CONTINENTAL
A5 INTERNATIONAL
A5 CART
