Anthos A3 Plus - Restorative Operating Mode; ENDODONTIC OPERATION MODE (LCD Touch Console Only)

A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
48
EN
5.5.1. RESTORATIVE OPERATING MODE
Characteristics.
• Speed range: 100 to 40,000 Rpm (1:1 handpiece).
• Reduction ratio selection.
• Display of the instantaneous maximum speed.
• Direct selection of the set working programmes.
Menu with micromotor extracted but not active.
All icon buttons are active and all available functions can be edited (see
paragraph 5.5.).
Any edited setting or value will be automatically saved inside
the selected working programme (e.g. P1).
Menu with micromotor extracted and active.
The following functions can be changed:
• Adjust the maximum rotation speed of the drill by using the “increase”
or “decrease“ buttons (E).
5.5.2. ENDODONTIC OPERATION MODE (LCD Touch console only)
Characteristics.
• Speed value adjustable from 100 to 1200 Rpm with value always
referring to the drill, based on the set reduction ratio,
• Torque adjustable from 0.1 to 5.0 Ncm,
• Reduction ratio selection with display of certified contra angles,
• Drill rotation set at maximum torque.
• Display of the instantaneous maximum speed.
• Direct selection of the set working programmes.
Disclaimer: The trademarks of the endodontic drills are not
the property of CEFLA s.c. or any of its affiliated companies.
Menu with micromotor extracted but not active.
In addition to the common buttons, the following buttons are also
available in ENDODONTIC mode:
B Torque value adjustment
S Drill rotation at maximum torque.
Torque value adjustment.
• Set the maximum torque value by using “increase” or “decrease“
buttons (B).
The torque value is expressed in % or Ncm for certified reducers.
The appearance of the symbol (Z) highlights a value reading tolerance of
±20%.
The data set are automatically saved.
