7.6. A.C.V.S. SYSTEM (AUTOMATIC CLEANING VACUUM SYSTEM)
Description of the system.
This system allows cleaning the suction lines.
The system features a tank with detergent fluid and two couplings used for suction tube flushing.
It is possible to choose between two flushing cycles of the suction ducts:
• STANDARD (1’:15’’)
• INTENSIVE (4’)
The cycles are automatic and are recommended after each operation (STANDARD cycle) and at the end of the day (INTENSIVE cycle) to complete the
cleaning and disinfection operations of the dental unit.
The INTENSIVE cycle is not available if the S.H.S. system is active.
Dental units of A3 PLUS, A5 and A6 PLUS models:
c Tank for detergent fluid.
d Couplings for suction tubes.
Dental units of L6 model:
c Tank for detergent fluid.
d Couplings for suction tubes.
How to start the flushing cycle.
To start the flushing cycle, proceed as specified below:
• Make sure that tank (c) contains enough detergent fluid.
• Remove both suction tube terminals from assistant's board supports,
making sure that suction motor starts.
• Open the mechanical covers of the suction tube terminals (opening
lever completely up).
• Insert suction tube terminals inside the relevant couplings (d) located
under manifold. The vacuum created inside the Venturi tubes starts the
flushing cycle.
• If you wish to proceed with the INTENSIVE cycle, press the button
(H1). The STANDARD washing cycle will start after more than 8
seconds of inactivity.
• Once cycle is over, the message "Put suction tubes back in place" will
appear on the DISPLAY.
• Now simply put suction tube terminals back into their supports on
assistant's board to go back to working condition.
Filling the tank.
It is recommended to use STER 3 PLUS (CEFLA s.c.) diluted in a 6% solution (equivalent to 60 ml of product in 1 litre of hot water).
STER 3 PLUS must be used as specified by the Manufacturer.
Dental units of A3 PLUS, A5 and A6 PLUS models:
• Move the dental chair fully up.
• Remove tank (c) by rotating it anti-clockwise.
• Pour the detergent liquid into the tank until it is full.
Tank capacity: 250 cc approx.
• Refit tank (c) by rotating it clockwise.
