A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
7.2. S.H.S. SYSTEM (SIMPLIFIED HYGIENIZATION SYSTEM)
Description of the system.
This system features a tank (a) suitable to contain the independent water
supply, preferably distilled water.
The tank has a total capacity of 1.8 litres and feeds:
• the sprays of all the instruments present on dentist's and
assistant's boards.
• the syringe present on the assistant's board.
• the cup filling system.
• the water quick coupling (if available).
The button (T) allows you to turn on/off the independent water supply.
Independent water supply active status is highlighted by icon
(A) appearing on the console DISPLAY.
Tank reserve warning.
When the fluid inside the tank drops below the reserve level, a special
warning icon (B) appears on dentist's board console.
Filling the tank.
Once tank min. level is reached (approx. 500 cc), fill it as follows:
• Press the button (T) to deactivate the independent water supply (icon
A not appearing on the DISPLAY).
• Remove tank (a) by rotating it anti-clockwise.
• Fill the tank until reaching the max. level.
Use distilled water or demineralised/deionised water. For
enhanced hygiene, it can be added with 600 parts per
million (ppm) of hydrogen peroxide by adding 35 ml of
Peroxy Ag+ or 35 ml of 3% Hydrogen Peroxide
(oxygenated water, 10 volumes)
• Refit tank by rotating it clockwise.
Make sure that tank is duly fastened.
• Touch the button (T) to re-enable the S.H.S. system.
Check that icon (A) on display turns on
If you are going to be absent from the surgery for long
periods of time (holidays), completely empty the tank (a)
before leaving. It is advisable to empty it by calling water
to the cup (use the cup supplied), until air comes out of
the nozzle.
