A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
Cleaning and disinfection of the tank.
It is recommended to periodically disinfect (at least once a month) the tank only, using as disinfectant Peroxy Ag+ Cefla or 3% Hydrogen Peroxide
(Oxygenated Water, 10 volumes), acting as follows:
• Remove tank from dental unit and drain it completely.
• Fill tank to the brim with the disinfectant.
• Allow the disinfectant to remain in the tank for at least 10 minutes.
• Drain disinfectant from the tank.
• Rinse tank with distilled water.
• Fill tank with distilled water, if necessary charging it with the substances indicated above.
• Fit tank back into its seat inside dental unit.
7.2.1. MANUAL S.H.S. SYSTEM
Fitted on models A3 PLUS, A5 SINGLE CART, SURGICAL SINGLE CART.
System features a tank (a) for distilled water.
The tank has a total capacity of 1.8 litres.
Tank supplies:
• The sprays of all the instruments present on dentist's and assistant's
boards.
• The cup filling system.
• The water quick coupling (if available).
With manual S.H.S. system: when it is not used for
approximately one month, we recommend against using the
water (about 50 cc) that first comes out of the quick coupling.
This system also allows performing a disinfection cycle of instrument
spray ducts using disinfectant in the tank instead of the supply liquid (see
paragraph 7.2.2.).
Activation/deactivation of independent water supply.
A by-pass toggle (b) allows you to activate/deactivate the independent
water supply:
• toggle on "TANK” position, independent water supply on,
• toggle on "LINE” position, mains water supply on
Tank reserve warning.
Visually check fluid level in the tank periodically as the system does not
feature any specific warning icon.
Filling the tank.
Once tank min. level is reached (approx. 500 cc), fill it as follows:
• Switch the toggle (c) to "CLOSE AIR PRESSURE” position.
• Remove tank (a) by turning it clockwise.
During this operation the pressurised air present inside the tank will be automatically bled to the outside.
• Pour distilled water inside the tank until reaching the max. level.
Use distilled water only. For enhanced hygiene, it can be added with 600 parts per million (ppm) of hydrogen peroxide using 20 ml
of Peroxy Ag+ per litre of distilled water, or oxygenated water (20 ml of 3% oxygenated water per litre of distilled water).
• Fit the tank back in place by turning it counter-clockwise.
• Switch the toggle (c) back to "OPEN AIR PRESSURE" position.
• Make sure that the tank is correctly secured in place before switching toggle (c) to "OPEN AIR PRESSURE" position.
• If you are going to be absent from the surgery for long periods of time (holidays), completely empty the tank (a) before leaving.
Cleaning and disinfection of the tank.
See paragraph 7.2.
