A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
3.1. CONVERSION OF THE DENTAL UNIT CONFIGURATION FOR LEFT-HANDED OPERATORS (HYBRID models only)
To reverse dental unit configuration, proceed as follows:
• Lower the dental chair and the backrest until the headrest is lower than
the water unit.
• Lift the dentist’s board up to its highest position.
• Turn the dentist’s board arm over the dental chair to reach the outer
side of the water unit and continue turning until reaching the end of
travel.
During this rotation, be careful to avoid any collision with
the water-to-cup spout.
• Move the dentist’s board arm back to the required position and place
the pantograph arm and the board in the optimal work positions.
• Now lift the backrest and move the assistant's board from the water
unit side to the opposite side, aiming it in the required direction.
• Finally, reverse the dentist’s board console position (see paragraph
5.).
To set the machine back to a configuration suitable for right-handed
people, repeat the indications from the first point, but reversing the
rotations of arms
