ARM Cortex-A9 MBIST User Manual

MBIST Datalog Register
4-2 Copyright © 2008 ARM Limited. All rights reserved. ARM DDI 0414C
Non-Confidential
Restricted Access
4.1 About the MBIST Datalog Register
The MBIST Datalog Register records information about failing arrays. The register is
79 bits long for each CPU. Figure 4-1 shows the register format.
Figure 4-1 MBIST Datalog Register format
Field descriptions on page 4-3 describes the register fields in detail.
The datalogs for all CPUs are dumped in parallel through MBISTRESULT[5:2] with:
• MBISTRESULT[5] for CPU3
• MBISTRESULT[4] for CPU2
• MBISTRESULT[3] for CPU1
• MBISTRESULT[2] for CPU0.
Failing address Failing CPU data out
Expected
data seed
78 68 67 4 3 0

ARM Cortex-A9 MBIST Specifications

General

Architecture	ARMv7-A
Clock Speed	Up to 2 GHz
Memory Management Unit	Yes
TrustZone	Yes
Core Count	1-4
Instruction Set	ARM, Thumb-2
Pipeline	8-stage
Floating Point Unit	VFPv3
NEON	Optional
L1 Cache	32KB Instruction, 32KB Data, per core
MBIST	Built-in Memory BIST
