136 DG14 and DG16 Board & Sensor Reference Manual
TRO Indicates whether tropospheric modelling is enabled (Y) or
disabled (N) in position computation. The tropospheric setting is
controlled by the ION setting. When ION is Y, then TRO is
automatically set to Y
Y, N
SAV Indicates whether user-entered parameters are saved (Y) or not
saved (N) in battery-backed memory. If user-entered parameters
are not saved, the default parameter settings are restored at the
next power cycle. Default is N.
Y, N
RTC Current RTCM differential mode setting. OFF indicates RTCM is
disabled; BAS indicates base station mode; REM indicates
remote mode. Default is OFF.
OFF, BAS, REM
PRT Port assignment for sending or receiving differential corrections. A, B, C
SBAS Indicates the SBAS modes • SAM: Single
Auto Mode
• DAM: Dual Auto
Mode
• SMM: Single
Manual Mode
• DMM: Dual
Manual Mode
NMEA Lists the NMEA and Ashtech NMEA-style messages supported
by the DG16.
LTN, POS, GLL,
GXP, GGA, VTG,
GSN, MSG, GSA,
GSV, SAT, GRS,
RRE, TTT, ZDA,
GST, GNS, CRT,
GDC, UTM, PTT,
UKO, SUD, DTM,
ALM
PRTA Indicates whether a given NMEA or Ashtech NMEA-style
message is enabled (ON) or disabled (OFF) for output from Port
A. Default is OFF.
ON, OFF
PRTB Indicates whether a given NMEA or Ashtech NMEA-style
message is enabled (ON) or disabled (OFF) for output from Port
B. Default is OFF.
ON, OFF
PER Output interval setting for NMEA and Ashtech NMEA-style
messages, excluding the TTT message. Default is 1 second.
0.05 to 999
Table 6.32. PAR Response Format (Continued)
Item Description Range
