316 DG14 and DG16 Board & Sensor Reference Manual
ADD: Add Frequency
$PASHS,BCN,DIR,ADD,f1,c1,f2,c2,f3,d1,d2,[d3,d4,d5,d6,d7]
This command adds a specified Beacon station to the beacon directory. Table 9.15
outlines the parameters.
The $PASHS,BCN,DIR,ADD command will be NAKed if you enter a station that is
located less than 30 Km from an existing station in the Beacon directory. To replace
a station, or edit one or more station parameters, you must delete the station and
add a new station with the new parameters.
Example
Enter the following command to add the Beacon station at Pigeon Point, CA to the
Beacon directory.
$PASHS,BCN,DIR,ADD,3711.33,N,122.2366,W,287.0,883,100
Table 9.15. $PASHS,BCN,DIR,ADD Parameters
Parameter Description Range
f1 Latitude 0 to 90.0000
c1 Direction of latitude N or S
f2 Longitude 0 to 180.0000
c2 Direction of Longitude E or W
f3 Beacon frequency, KHz 283.5 to 325.0
d1 Station ID 0 to 1023
d2 Bit rate 25, 50, 100, 200, none,
autodetect
d3 Optional. Range in Km
d4 Optional. Health
d5 Optional. Modulation code
d6 Optional. Synchronization type
d7 Optional. Broadcast coding
