22 DG14 and DG16 Board & Sensor Reference Manual
Figure 2.1 shows how to connect the components in the DG16 Board system.
Power
DG16 Board
Before applying power to the DG16 board, connect any controller devices or data
logging equipment to the input/output ports of the DG16 by way of connector
J301.
Figure 2.1. DG16 Board Connections
CAUTION
To avoid damage to the DG16, always turn off the power supply
before connecting or disconnecting power to the connector J301.
Interface
Cable
DG16 Board
Power I/O
Cable
Universal Power
Supply
Antenna
Antenna
Cable
