146 DG14 and DG16 Board & Sensor Reference Manual
Table 6.41 outlines the parameters.
Table 6.42 lists baud rate codes and the corresponding baud rates:
PWR: Receiver Power
$PASHS,PWR,OFF
This command turns the receiver power off. Any activity from the serial port turns
on the receiver power.
RID: Receiver Identification Parameters (Format 1)
$PASHQ,RID,[c1]
This command queries the various receiver identification parameters, where c1 is
the optional port designator for the output of the response. If a port is not specified,
the receiver sends the response to the current port.
Table 6.41. $PASHR,PRT Message Format
Parameter Description Range
c1 Identifier for the serial port to which you are
currently connected
A, B, C (optional)
d2 Baud rate code (see Table 6.42) 0 to 9
hh Checksum 2-character hex
Table 6.42. DG16 Baud Rate Codes
Code Baud Rate Code
Baud
Rate
0 300 5 9600
1 600 6 19200
2 1200 7 38400
3 2400 8 56800
4 4800 9 115200
DEFAULT SETTING
PRT—9600
